SMD 2835 LED Strip with Transistor | 15LEDs 10x503mm 24V High Performance
High-performance LED light strip FPC combining structural integrity, mechanical durability, and environmental adaptability for demanding lighting applications.
Product Overview
| Parameter |
Specification |
| Product Model |
HQ30156 |
| Product Name |
LED Light Strip FPC |
| Circuit Structure |
Double-layer circuit board |
| Surface Coating |
Double-sided black solder mask; black silk screen printing |
| Antioxidant Treatment |
OSP (Organic Solderability Preservative) |
| Core Performance |
Superior flexibility; excellent bending fatigue resistance; stable electrical conductivity |
| Design Standard |
Compliant with IPC-2221 general printed circuit board design specifications |
Technical Specifications & Customization
Dimensional Parameters
- Precision FPC: Maximum dimensions 240×500mm; no minimum size restriction
- Roll-type FPC: Maximum width 240mm; maximum length 100 meters
Circuit Layer Configurations
- Single-layer FPC: Cost-efficient for low-complexity circuits
- Double-layer FPC: Enhanced connectivity for high-integration applications
- Multi-layer FPC: Customizable for ultra-high-complexity scenarios
Solder Mask Options
- Yellow Solder Mask: Universal solution for general-purpose applications
- Black Solder Mask: Superior light absorption for high-end lighting systems
- White Solder Mask: High-reflectivity for professional lighting fixtures
Copper Foil Thickness
- Precision FPC: 12μm, 18μm, 35μm options
- Standard FPC: 18μm, 25μm, 35μm, 50μm options
Minimum Line Width/Spacing
Controlled to 3mil (0.076mm) as recommended practical limit for optimal manufacturing yield and reliability.
Core Performance & Quality Assurance
Flexibility & Bending Durability
Validated through rigorous testing with minimum 10,000 bending cycles per IPC standards, ensuring resistance to fatigue failure in dynamic applications.
Manufacturing Capabilities
20,000 sqm facility with 800+ employees and monthly output exceeding 5 million square meters, equipped with state-of-the-art German, Japanese, and Taiwanese machinery.
Customization Services
Technical Consultation
16 years of engineering expertise providing tailored solutions, drawing optimization, and material selection guidance.
Sample Fabrication
Expedited production line with 5-7 day lead time for double-layer samples and 3-5 days for single-layer samples, all validated through comprehensive testing.
Integrated Manufacturing
One-stop services covering substrate fabrication, precision circuit routing, custom mold development, and high-precision assembly with ±0.02mm tolerance.
Certifications & Compliance
ISO 9001 certified • UL 94 flame-retardant • RoHS compliant • REACH compliant
All materials meet international environmental standards with no restricted substances
Product images may show minor color variations due to lighting conditions. Actual products shall prevail. Our FPC portfolio undergoes regular technical upgrades to enhance performance and expand application scope.
